Star Cool

By carefully balancing compressor and fan speed, StarConomy accurately matches air circulation to cooling demand, ensuring an ideal environment for the produce while saving energy.

Operating the fans at reduced speed once the cargo is at set point means less cooling is needed, as the motors generate far less heat while using significantly less energy compared to operation at full speed.

• The standard reefer outlet is rated and
  protected to 32 Amps
• Star Cool’s main circuit protection is
  16 Amps; that is the system max rating
• 2.5 mm² (~14 AWG) cable is all that is required
• Two Star Cool units can run simultaneously on a single 32 Amp outlet

– Regardless of ambient, or set temp

– No special settings, changes or software

– Dual capability on standard reefer genset

• High definition, large size LCD
• User friendly, intuitive
• Easy access to temperature
  development graphs
• Logical keypad design
• Critical information on home screen
• 9 lines of data on display

• This proven and reliable speed control of the compressor secures optimal match between energy consumption and cooling capacity putting cargo care as 1st priority
• Dual compartment protects against water, moisture and dust – separated housing for print board and control/power connections
• Optimized design to protect against potential moisture, shock and extreme temperatures

Compressor

• The proven and reliable high-quality compressor is the heart of the cooling circuit
• Variable speed, 600 – 3300 rpm (20-110 Hz)
• Two-stage reciprocating for increased efficiency
• Lightweight aluminum, only 58 kg
• Maintenance-free, non-corrosive exterior made for the harsh marine environment
• Variable Compressor Speed
  = Most Efficient Capacity Control

• Digital setting for accuracy and safety (CMH/CFM)
• Alarm indication for open vent with frozen cargo or CA/AV operation
• Current vent position and changes to position logged to data memory
• Built in vacuum release safety

Factory charged with R134a, Star Cool R513A Optimized units allow for a switch of the refrigerant at any point in time without any change of software or hardware, offering a high level of flexibility and product security as future refrigerant regulations come into force.

Engineered for reliability, the Star Cool R513A Optimized units are designed for dual compatibility with R513A or R134a without compromising capacity or longevity.

An MCI purpose developed Smart Edge device including wide band 4G LTE with global coverage in a single device design, sharing battery with the reefer controller. The gateway connects the reefer container with the Sekstant Cloud and tailored OEM Sekstant user interface

Where the Star Cool Integrated combines the machine and box, the Star Cool Unit is built on the original concept of bolting the machine to a reefer box.
